Integrate GitHub with Zero Trust Network Access

In this topic, you will find general instructions on how to integrate GitHub with Portnox™ Zero Trust Network Access.

Note:
You can set up single sign-on in GitHub on organization level or on the enterprise level, depending on your needs. This guide shows how to set up single sign-on on organization level but the process is identical for the enterprise level.

Create a Portnox Cloud application configuration

In this step, you will create a configuration in Portnox Cloud that will contain all the information necessary to integrate with GitHub.

  1. In a new tab of your browser, open your Portnox Cloud account by accessing the following URL: https://clear.portnox.com/

    From now on, we will call this tab the Portnox tab.

  2. In the Cloud portal top menu, click on the Zero Trust Resources option.

  3. On the Resources screen, click on the Create resource button.

    1. In the What type of resource is this? section, select the SSO web application option.
    2. In the Authentication protocol section, select the SAML option.
    3. Click on the Next button.

  4. Optional: If you have more than one SAML identity provider configured, select the identity provider in the Select an identity provider to use for this resource section.
  5. In the Resource details section, enter a Resource name and optionally a Description.

    In this example, we used the name GitHub for the new application configuration but you can use any name you like.

  6. Keep this browser tab open. You will need it later.

Open your GitHub SAML SSO settings

In this section, you will access your GitHub administrative interface and find the SAML single sign-on (SSO) settings.

  1. In another tab of your browser, open your GitHub web interface by accessing the following URL: https://github.com/. Then, log in to your account.

    From now on, we will call this tab the GitHub tab.

  2. Go to your organization page, and then, in the left-hand side menu, click on the Authentication security option in the Security section.

    You can also go to the following URL: https://github.com/organizations/<your_org>/settings/security, replacing <your_org> with your organization identifier.

  3. In the SAML single sign-on section, activate the Enable SAML authentication checkbox.

Copy configuration values from the Portnox tab to the GitHub tab

In this section, you will copy the values displayed by Portnox Cloud and paste them in the relevant fields in the GitHub SAML SSO setup section.

  1. In the Portnox tab, in the Service details section, click on the  ⧉  icon next to the Identity Provider Entity ID / Audience URI field to copy the value.

  2. In the GitHub tab, click on the empty field next to the Issuer label and paste the value copied from Portnox Cloud.

  3. In the Portnox tab, in the Service details section, click on the  ⧉  icon next to the Sign-In URL / SSO URL field to copy the value.

  4. In the GitHub tab, click on the empty field next to the Sign on URL label and paste the value copied from Portnox Cloud.

  5. In the Portnox tab, in the Certificates > Signing certificates section, click on the  ⋮  icon next to the Active certificate and select the Copy certificate option to copy the certificate.

  6. In the GitHub tab, click on the empty field next to the Public certificate label and paste the value copied from Portnox Cloud.

Copy configuration values from the GitHub tab to the Portnox tab

In this section, you will copy the values displayed in your GitHub SAML SSO setup section, and paste them in the relevant fields in Portnox Cloud.

  1. In the GitHub tab, copy the URL labelled The assertion consumer service URL.

  2. In the Portnox tab, in the Resource properties section, click on the empty field under the Assertion Consumer Service (ACS) URL / Reply URL heading and paste the value copied from GitHub.

  3. In the Portnox tab, in the Resource properties section, click on the empty field under the Entity ID / Service Provider Entity URL heading and paste the same value. Then, remove the following trailing string from this value: /saml/consume, leaving only the first part of the URL as your Entity ID.

Finalize the configuration

In this section, you will finalize the configuration in Portnox Cloud and GitHub.

  1. Finalize the configuration in the Portnox tab.
    1. Optional: Click on the Next button, and in the Policy enforcement section, in the Device risk assessment section, change the setting to Override with custom policy and then select a risk assessment policy if you want to assess risk with this application using a custom risk assessment policy, and in the Access control section, change the setting to Override with custom policy and then select an access control policy if you want to control access to this application using a custom access control policy.
    2. Scroll all the way down to the end of the page, and then click on the Add resource button.

  2. Finalize the configuration in the GitHub tab.
    1. Click on the Test SAML configuration button and after a successful test, click on the Save SAML settings button.

Result: You have configured GitHub to be accessible using Portnox Zero Trust Network Access.

If needed, click on the People tab and configure individual users to require single sign-on when signing in.
